York
High-Efficiency Condensing Furnaces
Model Number Capacity Motor Type Gas Valve Type AFUE Documents
YP9C 60 - 120 MBH ECM, Modulating Modulating 97.5 - 98% Technical Guide Installation Manual
TM9Y 60 - 120 MBH ECM, 5 Speed Dual Stage 96% Technical Guide Installation Manual
TM9E 40 - 120 MBH ECM, 5 Speed Single Stage 95% Technical Guide Installation Manual
TG9S 40 - 130 MBH PSC, 4 Speed Single Stage 95.5% Technical Guide Installation Manual
Mixing boxes with economizer and CO2/DCV (Demand Controlled Ventilation) controls are available for all furnaces.

Standard-Efficiency Furnaces
Model Number Capacity Motor Type Gas Valve Type AFUE Documents
YPLC 60 - 120 MBH ECM, Modulating Modulating 80% Technical Guide Installation Manual
TMLY 60 - 120 MBH ECM, 5 Speed Dual Stage 80% Technical Guide Installation Manual
TMLX 60 - 120 MBH ECM, 5 Speed Single Stage 80% Technical Guide Installation Manual
TGLS 40 - 130 MBH PSC, 4 Speed Single Stage 80% Technical Guide Installation Manual
Mixing boxes with economizer and CO2/DCV (Demand Controlled Ventilation) controls are available for all furnaces.

Cooling-Only Condensing Units
Model Number Capacity Compressor Type Nominal Efficiency Documents
YXV 2 - 5 Tons Inverter Driven 19-20 SEER Technical Guide
CZH 2 - 5 Tons Dual Stage 18 SEER Technical Guide Installation Manual
CZF 2 - 5 Tons Single Stage 16 SEER Technical Guide Installation Manual
YCG 1.5 - 5 Tons Single Stage 17 SEER Technical Guide Installation Manual
YCS 1.5 - 5 Tons Single Stage 14 SEER Technical Guide Installation Manual
TCHE 2 - 4 Tons Side Discharge 14 SEER Technical Guide Installation Manual
TCHE (3-PH) 3 - 4 Tons Horizontal Discharge 14 SEER Technical Guide Installation Manual
TCG (3-PH) 3-5 Tons Single Stage 17 SEER Technical Guide Installation Manual
TCHD (3-PH) 3-4 Tons Side Discharge 14 SEER Technical Guide Installation Manual
TCD (3-PH) 2.5-5 Tons Single Stage 13 SEER Technical Guide Installation Manual

Heat Pump Condensing Units
Model Number Capacity Compressor Nominal Efficiency Documents
YZV 2 - 5 Tons Inverter Driven 19 -20 SEER Technical Guide Installation Manual
YZH 2 - 5 Tons Dual Stage 18 SEER Technical Guide Installation Manual
YZF 2 - 5 Tons Single & Dual 16 SEER Technical Guide Installation Manual
YHM 2 - 5 Tons Inverter Driven 16 SEER Technical Guide Installation Manual
YHE 1.5 - 5 Tons Single Stage 14 SEER Technical Guide Installation Manual
THE (3-PH) 3 - 5 Tons Single Stage 14 SEER Technical Guide Installation Manual

Fan Coils
Model Number Capacity Motor Type Description Documents
ADP AV 2 - 5 Tons ECM, Modulating High Efficiency, Variable Speed Technical Guide Installation Manual
ADP AX 2 - 5 Tons ECM, 5 Speed Standard Efficiency Technical Guide Installation Manual
AE 1.5 - 5 Tons ECM, 5 Speed Standard Efficiency Technical Guide Installation Manual
ME 2 - 5 Tons ECM, 5 Speed Modular Cabinet Technical Guide Installation Manual
AVC 1.5-5 Tons ECM, Modulating Communicating, Variable Speed Technical Guide Installation Manual
MVC 2 - 5 Tons ECM, Modulating Communicating, Modular Cabinet Technical Guide Installation Manual
AVV 2 - 5 Tons ECM, Modulating Communicating, Variable Speed with EEV Technical Guide Installation Manual
Mixing boxes with economizer and CO2/DCV (Demand Controlled Ventilation) controls are available for all fan coils.
Single-phase and three-phase electric heat kits are available for all fan coils

Low Profile Fan Coils (SunTherm)
Model Number Capacity Description Documents
CEHX-19-00-ED-0C74 1.5 Tons 14 SEER with YHE18 Heat Pump Technical Guide Installation Manual
CEHX-25-00-ED-0C74 2 Tons 14 SEER with YHE24 Heat Pump Technical Guide Installation Manual
CEHX-37-00-ED-0C74 2.5 Tons 14 SEER with YHE30 Heat Pump Technical Guide Installation Manual
HEC1-18-3-ACAJ-00 1.5 Tons 15.25 SEER with YHE18 Heat Pump Technical Guide Installation Manual
HEC1-24-3-BCAM-00 2 Tons 16 SEER with YHE24 Heat Pump Technical Guide Installation Manual
HEC1-30-1-CCAM-00 2.5 tons 15.75 SEER with YHE30 Heat Pump Technical Guide Installation Manual
HEC1-36-1-DCAM-00 3 Tons 16 SEER with YHE36 Heat Pump Technical Guide Installation Manual
SunTherm Fan coils are 11" high. York/SunTherm AHRI Ratings are available.

Furnace Coils
Model Number Capacity Description Documents
ADP CH 1.5 - 5 Tons Full Cased, Horizontal Technical Guide Installation Manual
ADP CV 1.5 - 5 Tons Full Cased, Upflow/Downflow Technical Guide Installation Manual
CM 1.5 - 5 Tons Full Cased, Multi-Position Technical Guide Installation Manual
CF 1.5 - 5 Tons Full Cased, Upflow/Downflow Technical Guide Installation Manual
CU 1.5 - 5 Tons Uncased, Upflow Technical Guide Installation Manual
